Horns Removal and Installation: Removal

WARNING: This page is about a different car, the 2005 Suzuki Reno and 2005 Suzuki Forenza. However, it is still accessible from the selected car via links, so may be relevant.
  1. Disconnect the negative battery cable.
  2. Disconnect the electrical connector.
  3. Remove the bolt and the horn. (Left horn shown, right horn similar, if equipped.)
    Fig 1: Removing Horn
    G04104435Courtesy of SUZUKI OF AMERICA CORP.
