Cigar Lighter Removal and Installation: Removal

WARNING: This page is about a different car, the 2005 Suzuki Reno and 2005 Suzuki Forenza. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the instrument panel center molding.
  2. Disconnect the cigar lighter and ashtray lamp electrical connector.
  3. Remove the cigar lighter housing from the instrument panel.
    Fig 1: Removing Cigar Lighter
    G04104401Courtesy of SUZUKI OF AMERICA CORP.
