Ashtray Removal and Installation: Installation

WARNING: This page is about a different car, the 2005 Suzuki Reno and 2005 Suzuki Forenza. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the ashtray housing with screws.
  2. Install the instrument panel center molding.
    Fig 1: Installing Ashtray Housing
    G04104400Courtesy of SUZUKI OF AMERICA CORP.
