Front Bumper Energy Absorber Removal and Installation: Removal

WARNING: This page is about a different car, the 2005 Suzuki Reno and 2005 Suzuki Forenza. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the front bumper fascia. Refer to "FRONT BUMPER FASCIA REMOVAL AND INSTALLATION :".
  2. Remove the energy absorber.
    Fig 1: Removing Front Bumper Fascia
    G04104755Courtesy of SUZUKI OF AMERICA CORP.
