Rotor Removal and Installation: Installation

WARNING: This page is about a different car, the 2005 Suzuki Reno and 2005 Suzuki Forenza. However, it is still accessible from the selected car via links, so may be relevant.
  1. Inspect the rotor. Refer to "ROTOR INSPECTION :".
  2. Install the rotor to the front wheel hub by tightening the detent screw.

    Tighten

    Tighten the rotor-to-front wheel hub detent screw to 4 N.m (35 lb-in).

  3. Install the caliper assembly. Refer to "CALIPER ASSEMBLY REMOVAL AND INSTALLATION :".
    Fig 1: Installing Rotor-To-Front Wheel Hub Detent Screw
    G04103305Courtesy of SUZUKI OF AMERICA CORP.
