Hatchback Weatherstrip Removal and Installation (For Station Wagon Model): Installation
WARNING: This page is about a different car, the 2005 Suzuki Reno and 2005 Suzuki Forenza. However, it is still accessible from the selected car via links, so may be relevant.
- Install the weatherstrip onto the gutter flange.
- Inspect the weatherstrip. Make sure that the clinch is completely seated onto the flange.
- Using a water hose without a nozzle, test the rear deck lid to make sure that no leaks are present.
- Install the luggage compartment rear quarter and rear trim panels. Refer to "LUGGAGE COMPARTMENT REAR TRIM PANEL REMOVAL AND INSTALLATION (FOR HATCHBACK MODEL) :".
