For station wagon model: Installation

WARNING: This page is about a different car, the 2005 Suzuki Reno and 2005 Suzuki Forenza. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the wheelhouse trim panel with the screws and the clips.
    CAUTION: Dissimilar metals in direct contact with each other may corrode rapidly. Make sure to use the correct fasteners to prevent premature corrosion.
  2. Install the D-pillar trim panel. Refer to "D-PILLAR TRIM PANEL REMOVAL AND INSTALLATION (FOR STATION WAGON MODEL) :".
  3. Install the rear wheelhouse trim panel. Refer to "REAR WHEELHOUSE TRIM REMOVAL AND INSTALLATION :".
  4. Install the C-pillar trim panel. Refer to "C-PILLAR TRIM PANEL REMOVAL AND INSTALLATION (FOR STATION WAGON MODEL) :".


  1. Install the tailgate lower garnish molding and screws.
    CAUTION: Dissimilar metals in direct contact with each other may corrode rapidly. Make sure to use the correct fasteners to prevent premature corrosion.
  2. Install the tailgate lower garnish molding upper screws.
    Fig 1: Installing Tailgate Lower Garnish Molding Upper Screws
    G04104646Courtesy of SUZUKI OF AMERICA CORP.
  3. Install the screws with the side molding.
    Fig 2: Installing Screws With Side Molding
    G04104647Courtesy of SUZUKI OF AMERICA CORP.
  4. Install the tailgate upper garnish molding cover and screws.
  5. Install the tail gate upper garnish molding. Refer to "TAILGATE UPPER GARNISH MOLDING REMOVAL AND INSTALLATION :".
    Fig 3: Installing Tailgate Upper Garnish Molding Cover And Screws
    G04104648Courtesy of SUZUKI OF AMERICA CORP.


  1. Install the tailgate upper garnish molding.
    CAUTION: Dissimilar metals in direct contact with each other may corrode rapidly. Make sure to use the correct fasteners to prevent premature corrosion.
