Front Strut Assembly Removal and Installation: Removal

Hoist vehicle, allowing front suspension to hang free.
Remove wheel and disconnect stabilizer joint (1) from strut bracket.

Fig 1: Disconnecting Stabilizer Joint
Courtesy of SUZUKI OF AMERICA CORP.
Remove brake hose mounting bolt (1) and take off brake hose (2) and then ABS wheel speed sensor harness (if equipped) from strut bracket as shown in the figure.
Remove strut bracket bolts (4).

Fig 2: Removing Brake Hose Mounting Bolt And Take Off Brake Hose
Courtesy of SUZUKI OF AMERICA CORP.
Remove strut support nuts (1).
NOTE: Hold strut by hand so that it will not fall off.

Fig 3: Removing Strut Support Nuts
Courtesy of SUZUKI OF AMERICA CORP.
Remove strut assembly.
