Clutch Pedal Position (CPP) Switch for Starter Inspection

Check for continuity between terminals of clutch pedal position switch (1). If found defective, replace switch.

Clutch pedal position (CPP) switch for starter specification

When switch shaft is free: No continuity

When switch shaft is pushed: Continuity

Fig 1: Checking Continuity Between Terminals Of Clutch Pedal Position Switch

Courtesy of SUZUKI OF AMERICA CORP.
