Upper Arm/Bushing Disassembly And Assembly: Disassembly

Cut rubber (1) of flange of upper arm bushing.
Using grinder (2), grind off flange (3) of upper arm bushing.
CAUTION: Be careful not to damage upper arm (4) when grinding flange (3) of upper arm bushing with grinder.

Fig 1: Grinding Flange Of Upper Arm Bushing With Grinder
Courtesy of SUZUKI OF AMERICA CORP.
Push out upper arm bushing by using hydraulic press (1) and special tool.
Special Tool
1. 09913-68711
Fig 2: Pushing Out Upper Arm Bushing Using Special Tool
Courtesy of SUZUKI OF AMERICA CORP.
