Rear Suspension Frame/Bushing Disassembly And Assembly: Disassembly

Cut rubber (1) of flange of rear suspension frame bushing.
Using grinder (2), grind off flange (3) of upper arm bushing.
CAUTION: Be careful not to damage rear suspension frame bushing (4) when grinding flange (3) of upper arm bushing with grinder.

Fig 1: Grinding Flange Of Upper Arm Bushing With Grinder
Courtesy of SUZUKI OF AMERICA CORP.
Push out rear suspension frame bushing by using hydraulic press (1) and special tool.
Special Tool
1. 09913-75520

  Fig 2: Pushing Out Rear Suspension Frame Bushing Using Special Tool
  Courtesy of SUZUKI OF AMERICA CORP.
