Passenger Air Bag (Inflator) Module Removal and Installation: Installation

Install passenger air bag (inflator) module (1) to instrument panel as shown.
Tighten passenger air bag (inflator) module attaching bolts (2) to specified torque.
Tightening torque

Passenger air bag (inflator) module attaching bolt a: 23 N.m (2.3 kg-m, 16.5 lb-ft)

Fig 1: Identifying Passenger Air Bag (Inflator) Module
Courtesy of SUZUKI OF AMERICA CORP.
Connect passenger air bag (inflator) module connector (1) securely as shown in the figure.
1. Connect connector.
2. Lock connector with lock button (2).

  Fig 2: Connecting Passenger Air Bag (Inflator) Module Connector
  Courtesy of SUZUKI OF AMERICA CORP.
Enable air bag system. Refer to ENABLING AIR BAG SYSTEM:EXCEPT ADVANCED AIR BAG .
