Body Dimension
>>
Under Body
>>
For HATCHBACK Model
April 5, 2026:
LEMON Manuals is launched!
Read the announcement.
For HATCHBACK Model
Unit: mm (in.)
Fig 1: Identifying Under Body Dimension Chart - Hatchback Model
Courtesy of SUZUKI OF AMERICA CORP.
Courtesy of SUZUKI OF AMERICA CORP.
