Valve Body Assembly Disassembly and Reassembly: Disassembly

  1. Pull out manual valve.
  2. Remove solenoid valves with O-ring by removing bolts.
    NOTE: Never reuse removed O-ring.
    Fig 1: Removing Solenoid Valves With O-Ring
    G04592055Courtesy of SUZUKI OF AMERICA CORP.
