Back Up Lamp Switch Removal and Installation: Removal

WARNING: This page is about a different variant/trim than selected.
  1. Disconnect negative cable at battery.
  2. Disconnect back up lamp switch coupler (1).
  3. Remove back up lamp switch.
    Fig 1: Disconnecting Back Up Lamp Switch Coupler
    G04592156Courtesy of SUZUKI OF AMERICA CORP.
