EGR Valve Assembly Removal and Installation: Removal

  1. Disconnect negative cable at battery.
  2. Disconnect EGR valve coupler.
  3. Remove EGR valve and gasket from intake collector.
Fig 1: Removing EGR Valve And Gasket From Intake Collector
G04097657Courtesy of SUZUKI OF AMERICA CORP.
