Axle Lock Actuator

Check if the gear of the axle lock actuator moves smoothly and the actuator expands (1) and contracts (2) by hand.

Actuator stroke

(a): 3mm (0.12 in.)

Fig 1: Checking Axle Lock Actuator

Courtesy of SUZUKI OF AMERICA CORP.
