Impact Beam Installation

  1. Install the impact beam with bolts-to-radiator centermember and front suspension centermember.

    Tighten

    Tighten the bolts-to-radiator centermember and front suspension centermember to 100 N.m (74 lb-ft).

    Fig 1: Installing Impact Beam With Bolts-To-Radiator Centermember And Front Suspension Centermember
    G04095026Courtesy of SUZUKI OF AMERICA CORP.
