DTC C2112 / C2380: Valve Relay or Fuse Failure / ABS / TCS Valve Error: Notes

Fig 1: DTC C2112 / C2380: Valve Relay Or Fuse Failure / ABS / TCS Valve Error - Circuit Diagram
G04095310Courtesy of SUZUKI OF AMERICA CORP.
