Power Sunroof Control Switch Removal

  1. Disconnect the negative battery cable.
  2. Pry off the interior courtesy lamp lens.
  3. Remove the screws and the switch.
  4. Disconnect the electrical connector.
    Fig 1: Removing Screws And Sunroof Control Switch
    G04096396Courtesy of SUZUKI OF AMERICA CORP.
