Windshield Wiper Motor Removal

Disconnect the negative battery cable.
Remove the screws and the left side portion of the cowl vent grille.
Remove the nut and the washer that secure the wiper arm linkage to the motor drive shaft.

Fig 1: Removing Nut And Washer That Secure The Wiper Arm Linkage To The Motor Drive Shaft

Courtesy of SUZUKI OF AMERICA CORP.

Pry the wiper arm linkage off the motor drive shaft.
Disconnect the electrical connector.
Remove the bolts and the wiper motor.

Fig 2: Removing Bolts And Wiper Motor
Courtesy of SUZUKI OF AMERICA CORP.
