Windshield Washer Pump Installation
- Install the washer pump.
- Connect the washer hose to the washer pump.
- Connect the electrical connector.
- Install the front wheel well splash shield. Refer to "FRONT WHEEL WELL SPLASH SHIELD INSTALLATION ".
- Install the right front wheel. Refer to "WHEEL INSTALLATION ".
- Connect the negative battery cable.
