Windshield Washer Hoses Installation

  1. Connect the washer hose to the washer pump.
  2. Install the front wheel well splash shield. Refer to "FRONT WHEEL WELL SPLASH SHIELD INSTALLATION ".
  3. Install the front right wheel. Refer to "WHEEL INSTALLATION ".
  4. Connect the windshield washer hose to the washer nozzles on the hood.
  5. Close the hood.
    Fig 1: Connecting Windshield Washer Hose To Washer Nozzles On Hood
    G04096204Courtesy of SUZUKI OF AMERICA CORP.
