Daytime Running Lamp Module Installation

  1. Connect the electrical connector.
  2. Install the daytime running lamp module with the screws.
  3. Install the stereo cassette radio. Refer to "STEREO CASSETTE AM/FM RADIO INSTALLATION ".
  4. Connect the negative battery cable.
    Fig 1: Connecting Electrical Connector
    G04096097Courtesy of SUZUKI OF AMERICA CORP.
