Front Door Glass Removal and Installation: Removal

  1. Remove the door seal trim. Refer to "DOOR SEAL TRIM REMOVAL AND INSTALLATION :".
  2. Remove the outside channel molding. Refer to "OUTSIDE CHANNEL MOLDING REMOVAL AND INSTALLATION :"
  3. Remove the screws that secure the glass to the window regulator.
  4. Remove the glass from the door.
    Fig 1: Removing Front Door Glass
    G04104509Courtesy of SUZUKI OF AMERICA CORP.
