Drive Range - Fourth Gear; Emergency/Substitute Mode

Fig 1: Drive Range - Fourth Gear - Emergency/Substitute Mode - Power Flow Diagram

Courtesy of SUZUKI OF AMERICA CORP.

In Drive 4, transaxle drive is via the input shaft and clutches E and C. The elements of this transaxle function are as follows:

• Clutch E is engaged to drive the rear planetary gear carrier.
• The rear planetary gear carrier drives the rear ring gear.
• The rear ring gear carrier drives the differential gear.
