DTC P0488 Exhaust Gas Recirculation Closed Valve Pintle Error: Notes

Fig 1: Exhaust Gas Recirculation Closed Valve Pintle Error - Circuit Diagram
G04102565Courtesy of SUZUKI OF AMERICA CORP.
