Inside Lock Rod Removal and Installation: Removal

  1. Remove the door seal trim. Refer to "DOOR SEAL TRIM REMOVAL AND INSTALLATION :".
  2. Remove the inside door handle. Refer to "INSIDE DOOR HANDLE REMOVAL AND INSTALLATION :".
  3. Disconnect the inside lock rods from the lock.
    Fig 1: Removing Inside Door Handle
    G04104533Courtesy of SUZUKI OF AMERICA CORP.
