Inside Lock Rod Removal and Installation: Installation

  1. Connect the inside lock rods to the lock.
  2. Install the inside door handle. Refer to "INSIDE DOOR HANDLE REMOVAL AND INSTALLATION :".
  3. Install the door seal trim. Refer to "DOOR SEAL TRIM REMOVAL AND INSTALLATION :".
    Fig 1: Installing Inside Door Handle
    G04104534Courtesy of SUZUKI OF AMERICA CORP.
