Removal & Installation
NOTE:
When replacing switch, use care not to let dust enter transmission through switch hole.
- Lift up vehicle.
- Remove coupler (1) for switch wiring. See Fig 1 .
- Replace back-up light switch (1).
- Check switch for proper function with ignition switch turned on and gear shifted to reverse position. Turn off switch after checking its function.
