Engine Block Heater Removal and Installation: Removal

  1. Disconnect negative cable at battery.
  2. Remove right side exhaust manifold referring to "EXHAUST MANIFOLD REMOVAL AND INSTALLATION ".
  3. Disconnect engine block heater connector and remove engine block heater (1).
    Fig 1: Disconnecting Engine Block Heater Connector & Removing Engine Block Heater
    G02256899Courtesy of SUZUKI OF AMERICA CORP.
