Exhaust Gas Recirculation (EGR) Valve Removal

  1. Disconnect the negative battery cable.
  2. Disconnect the EGR valve wiring harness connector.
  3. Remove the EGR valve.
  4. Remove the EGR valve gasket.
Fig 1: Removing EGR Valve Gasket
G01985513Courtesy of SUZUKI OF AMERICA CORP.
