Instrument Cluster Dimmer / Headlamp Leveling Switch Installation

  1. Replace the appropriate switch.
  2. Connect the electrical connectors.
  3. Install the instrument cluster dimmer/headlamp leveling switch assembly.
Fig 1: Installing Instrument Cluster
G02996840Courtesy of SUZUKI OF AMERICA CORP.
