Power Sunroof Control Switch Removal

  1. Disconnect the negative battery cable.
  2. Pry off the interior courtesy lamp lens.
  3. Remove the screws and the switch.
  4. Disconnect the electrical connector.
Fig 1: Disconnecting Power Sunroof Control Switch
G02997094Courtesy of SUZUKI OF AMERICA CORP.
