Power Sunroof Control Switch Installation

  1. Connect the electrical connector.
    CAUTION: Dissimilar metals in direct contact with each other may corrode rapidly. Make sure to use the correct fasteners to prevent premature corrosion.
  2. Install the sunroof control switch with the screws.
    1. Tighten the power sunroof control switch screws to 2 N.m (18 lb-in).
  3. Install the interior courtesy lamp lens.
  4. Connect the negative battery cable.
Fig 1: Installing Power Sunroof Control Switch
G02997095Courtesy of SUZUKI OF AMERICA CORP.
