Front Door Trim Panel Installation

  1. Install the door step lamp.
  2. Install the trim panel.
  3. Connect the electrical connectors.
  4. Install the rear deck lid remote switch and the power window/mirror control switch.
    Fig 1: Installing Door Step Lamp
    G02997027Courtesy of SUZUKI OF AMERICA CORP.
  5. Install the door trim panel screws.
    1. Tighten the door trim panel screws to 2.5 N.m (22 lb-in).
  6. Install the inside door handle trim bezel.
  7. Raise the front window.
Fig 2: Installing Inside Door Handle Trim Bezel
G02997028Courtesy of SUZUKI OF AMERICA CORP.
