Diagnostic Aids
DTC C0245 may be set by running the scan tool auto test if the throttle angle readings are not updating while in the data list mode. If this is the case, clear the DTCs, disconnect the scan tool, and road test the vehicle to at least 12 km/h (7 mph) to see if the DTC resets.
Check the toothed wheels for any large grooves, gouges, marks, etc. that might influence the tooth's signal at the wheel speed sensor. Also check for a buildup of foreign material in the gaps between teeth in the toothed wheel, this material may cause this malfunction.
A badly worn hub/bearing assembly may cause this malfunction. The wheel speed sensor-to-toothed wheel air gap may change excessively due to bearing play.
If an improper rear hub assembly or front outer constant velocity joint is installed, one with a toothed wheel containing the incorrect number of teeth, this DTC can set. Be sure that the front and the rear toothed wheel have 47 and 29 teeth.
