Air Bleeding

Bleed the hydraulic system to remove the air which entered when the pipes were disconnected for repairs. The clutch/brake fluid in the clutch/brake reservoir must be maintained at the MIN level or higher during air bleeding.

1. Attach a vinyl hose to the bleeder plug. Place the other end of the vinyl tube in a glass container half-filled with brake fluid.
2. Slowly pump the clutch pedal several times.
3. While you press the clutch pedal, loosen the bleeder screw until the fluid starts to run out. Close the bleeder screw.
4. Repeat step  3 until there are not air bubbles in the fluid.
5. Fill the reservoir with brake fluid up to the proper level.
   Fig 1: Filling The Reservoir With Brake Fluid

   Courtesy of SUZUKI OF AMERICA CORP.
