The Benefits of EBD

The Benefits of EBD
^ Elimination of conventional proportioning valve.
^ EBD utilizes the existing rear axle wheel speed sensor to monitor rear wheel slip.
^ Based on many variables in algorithm a pressure hold, increase and/or decrease pulsetrain may be triggered at the rear wheels insuring vehicle stability.
^ Vehicle approaches the ideal brake force distribution. (front to rear)
^ Constant brake force distribution during vehicle lifetime. EBD function is monitored via ABS safety logic. (conventional proportioning valves are not monitorable)
^ "Keep alive" function.





Electronic Brake-Force Distribution (EBD) Failure Matrix
