DTC P1871: EDS Valve Power Supply Circuit Shorted to Power: Notes

Fig 1: DTC P1871 EDS Valve Power Supply Circuit Shorted to Power Diagnostic Wiring Diagram
G00785309Courtesy of SUZUKI OF AMERICA CORP.
