CROSSMEMBER Removal And Installation: Installation

  1. Install the crossmember.
  2. Install the crossmember-to-body bolts.

    Tighten

    Tighten the crossmember-to-body bolts to 112 N.m (83 Ft. Lbs.).

    Fig 1: Installing The Crossmember-To-Body Bolts
    G00766988Courtesy of SUZUKI OF AMERICA CORP.
  3. Route and install the rear wheel speed sensor wiring.
  4. Install the rear parallel link bolt onto the crossmember. Refer to REAR PARALLEL LINK REMOVAL AND INSTALLATION  .
  5. Install the front parallel link bolt onto the crossmember. Refer to FRONT PARALLEL LINK REMOVAL AND INSTALLATION  .
  6. Lower the vehicle.
