A/C Refrigerant Pressure Switch Removal and Installation: Removal
WARNING: This page is about a different car, the 2004 Suzuki Aerio. However, it is still accessible from the selected car via links, so may be relevant.
- Disconnect negative cable at battery.
- Recover refrigerant from A/C system referring to Operation Procedure for Refrigerant Charging .
- Disconnect A/C refrigerant pressure switch connector (1).
- Remove A/C refrigerant pressure switch (2) from refrigerant pipe.
CAUTION:
Be careful to distort refrigerant pipe.
