Transfer 4WD Switch Inspection
- Undo clamp and disconnect coupler of 4WD switch.
- Function of transfer 4WD (1) switch can be checked as shown in the figure.
There should be conduction at these terminals when shift lever is shifted to "4H", and "4L" positions.
- Upon completion of check, connect coupler and clamp wiring harness as they were.
NOTE:
When replacing switch(es), use care not to let dust enter transfer through switch hole.
