EGR Valve Assembly Removal and Installation: Removal

  1. Disconnect negative (-) cable at battery.
  2. Disconnect EGR valve coupler.
  3. Remove wire harness bracket from intake collector.
  4. Remove EGR valve (5) and gasket from intake collector.
    Fig 1: Removing EGR Valve
    G01374984Courtesy of SUZUKI OF AMERICA CORP.
