G Sensor Removal And Installation: Removal

Turn ignition switch to "OFF" position and disconnect battery negative cable.
Remove rear center console box.
Remove parking brake lever bolts (rear side) (3) and G sensor (2) with bracket from floor.
NOTE: Loosen only bolt (front side) (4).
Remove sensor (2) with bracket from floor.
Disconnect connector from sensor (2).

CAUTION:

Do not separate sensor (2) and bracket (5). It will lead to erroneous assembly.
Sensor must not be dropped or shocked. It will affect its original performance.

Fig 1: Removing G Sensor With Bracket From Floor
Courtesy of SUZUKI OF AMERICA CORP.
