Back Up Light Switch Removal & Installation

WARNING: This page is about a different car, the 2004 Suzuki XL-7. However, it is still accessible from the selected car via links, so may be relevant.

WARNING: Refrain from work while exhaust center pipe is hot.

NOTE:

When replacing switch, use care not to let dust enter transmission through switch hole.

Lift up vehicle.
Remove coupler (1) for switch wiring.

Fig 1: Removing Coupler For Switch Wiring
Courtesy of SUZUKI OF AMERICA CORP.
Replace back up light switch (1).
Tightening torque

Back up light switch (a): 45 N.m (4.5 kg-m, 32.5 lb-ft)

Fig 2: Replacing Back Up Light Switch
Courtesy of SUZUKI OF AMERICA CORP.
Check switch for proper function with ignition switch turned ON and gear shifted to reverse position. Turn OFF switch after checking its function.
