Removal & Installation (Montero)
WARNING: This page does not describe the selected car, but rather 7 other vehicles, including the 2003 Mitsubishi Outlander, 2003 Mitsubishi Montero Sport, 2003 Mitsubishi Montero, 2003 Mitsubishi Lancer, and 2003 Mitsubishi Galant. However, it is still accessible from the selected car via links, so may be relevant.
Remove EVAP emission ventilation solenoid. See EVAP EMISSION VENTILATION SOLENOID under MOTORS, RELAYS & SOLENOIDS. Remove cap and vent hoses from ORVR vent valve module. See Figure. Remove vent pipe. Remove bracket from ORVR vent valve module. To install, reverse removal procedure.
