A/C Controller Removal & Installation: Removal

WARNING: This page is about a different car, the 2003 Suzuki Vitara, 2003 Suzuki Grand Vitara, 2002 Suzuki Vitara, and 2002 Suzuki Grand Vitara. However, it is still accessible from the selected car via links, so may be relevant.

Disconnect negative (-) cable at battery.
Disable air bag system, if equipped. See DISABLING & ACTIVATING AIR BAG SYSTEM .
Open glove box, then remove screw.
Remove glove box.
Disconnect A/C controller coupler (2), evaporator thermistor coupler (3).
Remove A/C controller (1) from heater unit (4).

Fig 1: Removing A/C Controller
Courtesy of SUZUKI OF AMERICA CORP.
