Head Lining Removal And Installation: Installation

WARNING: This page is about a different car, the 2004 Suzuki XL-7, 2004 Suzuki Grand Vitara, 2003 Suzuki XL-7, and 2003 Suzuki Grand Vitara. However, it is still accessible from the selected car via links, so may be relevant.

Reverse removal procedure to install head lining noting the following instructions.

Set roof harness (1) and rear washer hose (2) to head lining (3) with adhesive tape (5) as shown.
For without sunroof model, apply double coated tape (4) to head lining as shown.

Fig 1: Installing Head Lining
Courtesy of SUZUKI OF AMERICA CORP.
Tighten seat belt anchor bolt as specified torque referring to SEAT BELT CONSTRUCTION "Seat Belt Construction:".
Install door opening trim (1) as shown.

Fig 2: Installing Door Opening Trim

Courtesy of SUZUKI OF AMERICA CORP.
