Cylinder Block Specifications
CYLINDER BLOCK
| Application | In. (mm) | ||||
|---|---|---|---|---|---|
| Cylinder Bore | |||||
| Standard Diameter (1) | |||||
| "1" | 2.9138-2.9142 (74.010-74.020) | ||||
| "2" | 2.9134-2.9138 (74.000-74.010) | ||||
| Maximum Taper | .0039 (.10) | ||||
| Maximum Out-Of-Round | .0039 (.10) | ||||
| Maximum Deck Warpage | .002 (.05) | ||||
|
|||||
